Iframe Agent Specs - MuleRun Docs

🔍 Introduction

iframe is a standard protocol for embedding one website into another.
Iframes are particularly useful for enabling third-party agents with existing web applications to seamlessly onboard onto the MuleRun platform.
MuleRun supports Iframe Agents as one of its primary agent integration methods, allowing external developers to host and manage their agent logic independently while being securely embedded within MuleRun.

🏗️ System Architecture

Component Summary

Component	Description
Agent Configuration Params	The param details when you create an Iframe agent from Creator Studio iframe agent template
Iframe URL Protocol	The URL(s) that MuleRun opens when a user starts or resumes a session. Parameters are passed via query string for authentication and context. Separate URLs can be configured for starting and sharing sessions.
Metering API	A MuleRun platform API that allows agent creators to report usage costs for a given session. Enables fine-grained billing based on resource consumption.
Metering Get Reports API	A MuleRun platform API that allows agent creators to get the usage costs for a given session and its current session status.

📈 Agent Configuration Params

Configuration Param	Usage	Default
Start Session Url	The Iframe url that starts a new session on creator’s website
Share Session Url	The Iframe url that starts a new shared session(playback) on creator’s website
Agent Key	The key used for generating signature AND calling metering api, this key should not be expose to any 3rd party
Max Age	The maximum age of the session, in minutes	2880
Start Session Refresh Interval	The time interval between every two re-generations of start session full url(in minutes). when set to 0, it means the start session url will be created only once.	0

🔌 Iframe URL Protocol

Behavior Overview

When a new session starts, MuleRun redirects the user to the Start Session URL, including all required parameters.
On page refresh or re-entry into the session, the Start Session URL is loaded again with updated parameters.
When a session ends (either terminated or time out), a Share Session URL may be triggered. The user may choose to view or share the session playback.
When a visitor accesses the shared playback of a session, the Share Session URL is opened.

URL Schema Design

https://{start-session-url}?
  userId={user_id}&
  sessionId={session_id}&
  agentId={agent_id}&
  time={unix_timestamp}&
  signature={hmac_signature}&
  origin={platform_origin}&
  nonce={nonce}

Note: All parameters are URL-encoded during transmission. During signature verification, they must be URL-decoded, parsed into a dictionary, sorted, and serialized as JSON before HMAC calculation.

Routing Example

Your agent’s endpoint: https://third-party-url.com/session/

Parameter Definitions

Parameter	Type	Example
`userId`	string (64 chars)	`3e5215afce4ef92284c336110cc6dd3d0107971687396cbb3dbbbc625bc3807d`
`sessionId`	string (36 chars, UUID)	`7469a916-d0c6-4161-bd33-1ebac5c834c4`
`agentId`	string (36 chars, UUID)	`924751e0-196e-4b22-bdbd-f0a9ac6a4e39`
`time` (UTC)	string (integer timestamp)	`1755667994`
`origin`	string	`mulerun.com`
`nonce`	string (36 chars, UUID)	`bd3ff1f9-d5f3-4019-848a-7c74bba0b73a`
`signature`	string (64 chars, SHA-256 HMAC hex)	`2ae8a94f29beda81f59beca248824fcd91484c5f5744432a47ce2cea0a5c9a6f`

Example URL

https://third-party-url.com/session?
  userId=377860de68ec786a091beb5d62836797bac4cf98074bd74af56bcec863696146&
  sessionId=25404aaa-b407-4da7-9eb5-8ea6cbcfc9ee&
  agentId=924751e0-196e-4b22-bdbd-f0a9ac6a4e39&
  time=1755671232&
  origin=mulerun.com&
  nonce=bd3ff1f9-d5f3-4019-848a-7c74bba0b73a&
  signature=dd4f2b82b054ce4324175c83ea9219772caa08863ba76e47cc7f03c57a65ce76

Signature Generation (Python Example)

import json
from datetime import datetime, timezone
import hmac
from hashlib import sha256

nonce = "bd3ff1f9-d5f3-4019-848a-7c74bba0b73a"
request_params = {
    "userId": user_sha_id,
    "sessionId": str(session_id),
    "agentId": "924751e0-196e-4b22-bdbd-f0a9ac6a4e39",
    "time": str(int(datetime.now(timezone.utc).timestamp())),
    "origin": "mulerun.com",
    "nonce": nonce,
}

# Ensure parameters are sorted by key before serialization
sorted_json = json.dumps(request_params, separators=(',', ':'), sort_keys=True)
signature = hmac.new(agent_key.encode(), json.dumps(request_param, sort_keys=True, separators=(',', ':')).encode(), sha256).hexdigest()

request_params["signature"] = signature

✅ Important: Use json.dumps(..., sort_keys=True) to ensure consistent serialization order.

Signature Verification (Python Example)

from urllib.parse import parse_qs
import hmac
from hashlib import sha256
import json

agent_key = "your-agent-key"  # Shared secret between MuleRun and Agent
query_string = "userId=...&signature=..."

# Parse query string
query_dict = {k: v[0] if len(v) == 1 else v for k, v in parse_qs(query_string).items()}
received_signature = query_dict.pop("signature")

# Recreate canonical string for HMAC
sorted_payload = json.dumps(query_dict, separators=(',', ':'), sort_keys=True)
calculated_hmac = hmac.new(
    agent_key.encode(),
    sorted_payload.encode(),
    sha256
).hexdigest()

# Secure comparison
if hmac.compare_digest(calculated_hmac, received_signature):
    # Valid request
    pass
else:
    # Invalid or tampered request
    raise Exception("Invalid signature")

🔐 The agent_key is your Agent specific key that you can copy from your agent info in Creator Studio. It should be not be exposed to any 3rd party.

🔒 Security Considerations

To ensure secure and trusted communication, the following mechanisms are implemented:

Mechanism	Purpose
User ID Hashing	Raw user identifiers are hashed (e.g., SHA-256) to protect user privacy.
HMAC Signature	Prevents tampering of query parameters. Ensures authenticity of the request.
Timestamp Validation	Requests must be within a valid time window (e.g., ±5 minutes) to prevent replay attacks.
Origin Domain Whitelisting	Only specified domains are allowed to receive iframe requests. Prevents unauthorized embedding.
Nonce Usage	Unique per-request identifier to prevent replay attacks and ensure freshness.

✅ Recommended Validation Logic:

📊 Metering Report API

Used by agents to report usage and enable accurate billing.

Endpoint

POST https://mulerun.com/v1/metering/report
This is a temporary endpoint that will be moved to https://api.mulerun.com/sessions/metering/report in October 2025

Headers

Header	Type	Required	Description
`Authorization`	string	Yes	Bearer token: `Authorization: Bearer <your_agent_key_here>`
`Content-Type`	string	Yes	Must be `application/json`

Request Body

{
  "agentId": "123e4567-e89b-12d3-a456-426614174000",
  "sessionId": "987e6543-e21b-45cd-b678-123456789abc",
  "cost": 1050,
  "timestamp": "2023-10-27T10:00:00Z",
  "isFinal": false,
  "meteringId": "abc123efg-456h-789i-jklm-123nop456qr"
}

Field Descriptions

Field	Type	Required	Description
`agentId`	string (UUID)	Yes	Unique ID assigned by MuleRun to identify the agent.
`sessionId`	string (UUID)	Yes	Identifier for the current user session. Multiple reports with the same `sessionId` belong to the same session.
`cost`	integer	Yes	Usage cost in units of 0.0001 credits. For example, `1050` = 0.105 credits. Must be positive.
`timestamp`	string (ISO 8601 UTC)	Yes	UTC timestamp indicating when this usage was recorded.
`isFinal`	boolean	No	If `true`, marks this as the final report for the session(AND session will be terminated). Defaults to `false`.
`meteringId`	string (UUID v4 recommended)	Yes	A globally unique idempotency key. Prevents duplicate processing of the same report.

✅ Idempotency Mechanism

New meteringId: The request is processed and stored. A success response is returned.
Duplicate meteringId: The system returns the cached response without reprocessing.
This ensures safe retries without double billing.

📜 Additional Billing & Session Rules

1. Timestamp Ordering

All metering reports must have monotonically increasing timestamp values.
Out-of-order reports may be rejected or handled with warnings during auditing.

2. Final State Idempotency

Once a report with "isFinal": true is accepted for a sessionId, the session is marked as completed.
Any further reports for the same sessionId will be ignored (cached response returned).

3. Session Termination Handling

No Reports Received: If no metering reports are sent, MuleRun will charge based on internal resource tracking.
Grace Period: If no final report is received before session end, late reports are accepted within 1 minute after termination.
Abnormal Termination: In cases of crash or forced termination, the grace period does not apply — charges are settled immediately.

4. Negative Credit Balance

If a user’s credit balance becomes negative, the session is immediately terminated.
All subsequent metering reports for that session will be ignored.

✅ Success Response

{
  "status": "success",
  "meteringId": "abc123efg-456h-789i-jklm-123nop456qr"
}

Field	Type	Description
`status`	string	`"success"` indicates the report was accepted.
`meteringId`	string	The idempotency key stored by MuleRun for this record.

❌ Error Responses

`400 Bad Request`

{
  "error": {
    "type": "invalid_request_error",
    "message": "Parameter 'cost' must be a positive number."
  }
}

`401 Unauthorized`

{
  "error": {
    "type": "authentication_error",
    "message": "Invalid or missing authentication token."
  }
}

`429 Too Many Requests`

{
  "error": {
    "type": "rate_limit_error",
    "message": "You have exceeded the rate limit."
  }
}

`500 Internal Server Error`

{
  "error": {
    "type": "api_error",
    "message": "An internal error occurred. Please try again."
  }
}

💡 Example cURL Request

curl -X POST "https://api.mulerun.com/v1/metering/report" \
  -H "Authorization: Bearer <your_agent_key_here>" \
  -H "Content-Type: application/json" \
  -d '{
    "agentId": "123e4567-e89b-12d3-a456-426614174000",
    "sessionId": "987e6543-e21b-45cd-b678-123456789abc",
    "cost": 1050,
    "timestamp": "2023-10-27T10:00:00Z",
    "isFinal": false,
    "meteringId": "abc123efg-456h-789i-jklm-123nop456qr"
  }'

🛠️ Best Practice: Generate a new UUIDv4 for each meteringId to ensure idempotency.

📊 Metering Get Reports API

API Endpoint

GET https://mulerun.com/v1/metering/session/{sessionId}
This is a temporary endpoint that will be moved to https://api.mulerun.com/sessions/metering/session/{sessionId} in October 2025

Headers

Name	Type	Required	Description
`Authorization`	string	Yes	Bearer token for authentication. Example: `Authorization: Bearer <your_agent_key_here>`

Path Parameters

Parameter Name	Type	Required	Description
`sessionId`	string	Yes	Unique identifier of the session, passed via URL path

Response Format

✅ Success Response

{
  "status": "success",
  "data": {
    "sessionId": "987e6543-e21b-45cd-b678-123456789abc",
    "sessionStatus": "completed",
    "reportCount": 3,
    "isFinalReported": true,
    "meteringRecords": [
      {
        "meteringId": "abc123efg-456h-789i-jklm-123nop456qr",
        "isFinal": false
      },
      {
        "meteringId": "def456hij-789k-012l-mnop-456qrs789tuv",
        "isFinal": false
      },
      {
        "meteringId": "ghi789klm-012n-345o-pqrs-789tuv012wxy",
        "isFinal": true
      }
    ]
  }
}

Field Descriptions

Top-Level Fields

Field	Type	Description
`status`	string	Fixed value `"success"`, indicates the query was successful
`data`	object	Contains detailed session information

`data` Object Fields

Field	Type	Description
`sessionId`	string	Unique identifier of the session
`sessionStatus`	string	Current status of the session. Possible values: `running` (in progress), `completed` (ended normally), `error` (ended with error)
`reportCount`	number	Number of successfully processed metering reports
`isFinalReported`	boolean	Whether the final report (`isFinal=true`) has been received
`meteringRecords`	array	List of successfully processed metering records

Elements in `meteringRecords` Array

Field	Type	Description
`meteringId`	string	Unique identifier from the metering API request
`isFinal`	boolean	Indicates whether this is the final record

Session Status Descriptions

Status Value	Description
`running`	The session is active and can accept new metering requests
`completed`	The session has ended normally (either `isFinal=true` was reported or the session terminated properly)
`error`	The session ended abnormally (e.g., platform failure or other errors)

Error Responses

❌ 400 Bad Request — Invalid request parameters

{
  "error": {
    "type": "invalid_request_error",
    "message": "Invalid request params"
  }
}

❌ 401 Unauthorized — Authentication failed

{
  "error": {
    "type": "authentication_error",
    "message": "Invalid authentication token"
  }
}

❌ 404 Not Found — Session does not exist

{
  "error": {
    "type": "not_found_error",
    "message": "Invalid session_id, session not found"
  }
}

❌ 403 Forbidden — Insufficient permissions

{
  "error": {
    "type": "permission_error",
    "message": "Permission denied, not authorized to this session"
  }
}

❌ 500 Internal Server Error — Internal server error

{
  "error": {
    "type": "api_error",
    "message": "An internal error occurred. Please try again."
  }
}

Example Request

curl -X GET "https://mulerun.com/v1/metering/session/987e6543-e21b-45cd-b678-123456789abc" \
  -H "Authorization: Bearer <your_agent_key_here>"

First steps

Creator Studio

Agent

Pricing

Marketing

​🔍 Introduction

​🏗️ System Architecture

​Component Summary

​📈 Agent Configuration Params

​🔌 Iframe URL Protocol

​Behavior Overview

​URL Schema Design

​Routing Example

​Parameter Definitions

​Example URL

​Signature Generation (Python Example)

​Signature Verification (Python Example)

​🔒 Security Considerations

​📊 Metering Report API

​Endpoint

​Headers

​Request Body

​Field Descriptions

​✅ Idempotency Mechanism

​📜 Additional Billing & Session Rules

​1. Timestamp Ordering

​2. Final State Idempotency

​3. Session Termination Handling

​4. Negative Credit Balance

​✅ Success Response

​❌ Error Responses

​400 Bad Request

​401 Unauthorized

​429 Too Many Requests

​500 Internal Server Error

​💡 Example cURL Request

​📊 Metering Get Reports API

​API Endpoint

​Headers

​Path Parameters

​Response Format

​✅ Success Response

​Field Descriptions

​Top-Level Fields

​data Object Fields

​Elements in meteringRecords Array

​Session Status Descriptions

​Error Responses

​❌ 400 Bad Request — Invalid request parameters

​❌ 401 Unauthorized — Authentication failed

​❌ 404 Not Found — Session does not exist

​❌ 403 Forbidden — Insufficient permissions

​❌ 500 Internal Server Error — Internal server error

​Example Request

🔍 Introduction

🏗️ System Architecture

Component Summary

📈 Agent Configuration Params

🔌 Iframe URL Protocol

Behavior Overview

URL Schema Design

Routing Example

Parameter Definitions

Example URL

Signature Generation (Python Example)

Signature Verification (Python Example)

🔒 Security Considerations

📊 Metering Report API

Endpoint

Headers

Request Body

Field Descriptions

✅ Idempotency Mechanism

📜 Additional Billing & Session Rules

1. Timestamp Ordering

2. Final State Idempotency

3. Session Termination Handling

4. Negative Credit Balance

✅ Success Response

❌ Error Responses

`400 Bad Request`

`401 Unauthorized`

`429 Too Many Requests`

`500 Internal Server Error`

💡 Example cURL Request

📊 Metering Get Reports API

API Endpoint

Headers

Path Parameters

Response Format

✅ Success Response

Field Descriptions

Top-Level Fields

`data` Object Fields

Elements in `meteringRecords` Array

Session Status Descriptions

Error Responses

❌ 400 Bad Request — Invalid request parameters

❌ 401 Unauthorized — Authentication failed

❌ 404 Not Found — Session does not exist

❌ 403 Forbidden — Insufficient permissions

❌ 500 Internal Server Error — Internal server error

Example Request
